T251 / T301 / T401 / T501
Slimmer and lighter – 14.3 lb /13.2 lb for each panel
Easy to install and dismantle quickly without tools
Horizontal & vertical fast-lock
Front and rear serviceable
Sharp color & brightness uniformity
Wide horizontal & vertical viewing angle
SMD 2020 Pixel Configuration
Grayscale : 16 bits
Refresh Rate : 1920 Hz / 3840 Hz
Panel Size : 1'7" * 1'7" * 2"
Viewing Angle : 140º / 140º
IP Rating : IP40 / IP21
Individual Model Specifications
T251
Pixel Pitch : 2.5 mm
Pixel Matrix Per Panel : 192 x 192
Panel Weight : 14.3 lb / 6.5kg
Brightness : 1,000 nits
T301
Pixel Pitch : 3 mm
Pixel Matrix Per Panel : 160 x 160
Panel Weight : 13.7 lb / 6.2kg
Brightness : 1,000 nits
T401
Pixel Pitch : 4 mm
Pixel Matrix Per Panel : 120 x 120
Panel Weight : 13.2 lb / 6kg
Brightness : 800 nits
T501
Pixel Pitch : 5 mm
Pixel Matrix Per Panel : 96 x 96
Panel Weight : 13.2 lb / 6kg
Brightness : 800 nits
